White Vector Spot
QN 12161-417An adjustable surface-mounted cylinder in the Vector family, finished in Sandy White, with a swivelling head on a fixed round base that aims the beam independent of mounting. Beam angle (16°–50°) and CCT (3000K/4000K) are order options, so one body covers a wide throw range. For accent and display lighting where the aim needs adjusting after installation.
White Vector Spot (QN 12161-417) is built as a surface luminaire and specified at LED 8W, with 3000K / 4000K (order option), a colour rendering index of CRI ≥90 and IP44 ingress protection. It is finished in Sandy White, and is typically specified for residential, hotel, office schemes. Dimensioned drawings are shown below, photometric files are downloadable on this page, and finish samples are available on request.
| Luminous flux, lm | 539–554lm (16°) · 516–533lm (24°) · 526–542lm (36°) · 531–548lm (50°), 3000K/4000K |
| CCT, K | 3000K / 4000K (order option) |
| Power consumption, W | 8W · 36V / 200mA |
| Color rendering (CRI) | ≥90 |
| Glare rating (UGR) | <10 (16°/24°) / <14 (36°) / <22 (50°) |
| IP Code | IP44 |
| Size | Ø 38 × H 99 |
| Finishes |
Applications
Configure Vector
Your configuration
Dimensions & mounting
| Mounting | Surface |
| Dimensions, mm | Ø 38 × H 99 |
| Case material | Aluminum |
Light distribution — cd/klm
