Arco series · Offset ring pendant
Arco Pendant Light
QN 34172-003Asymmetric ring geometry on an offset stem. Up-down light and downlight versions; diameter options Ø 400 and Ø 600.
Arco Pendant Light (QN 34172-003) is built as a pendant luminaire and specified at LED 6W+14W, with 3000K, a colour rendering index of CRI ≥90 and IP20 ingress protection. It is finished in Sandy White, Sandy Black, Matte Silver, Matte Coffee, Matte Brass, and is typically specified for residential, hotel, restaurant schemes. Dimensioned drawings are shown below; IES / LDT photometric files and finish samples are supplied on request for specification and lighting-calculation work.
| Luminous flux, lm | 1900lm |
| CCT, K | 3000K |
| Power consumption, W | 6W+14W · 36V / 500mA |
| Color rendering (CRI) | ≥90 |
| Glare rating (UGR) | — |
| IP Code | IP20 |
| Size | Ø 400 / Ø 600 × Drop 2000 |
| Finishes |
Applications
ResidentialHotelRestaurant
Configure Arco
Your configuration
CodeQN 34172-003
FinishSandy White / Sandy Black / Matte Silver / Matte Coffee / Matte Brass
PriceSign in to view
Dimensions & mounting
| Mounting | Pendant |
| Dimensions, mm | Ø 400 / Ø 600 × Drop 2000 |
| Case material | Aluminum |
| Warranty | 3 years |
Light distribution — cd/klm
C0 / C180 — up-down version
