Luna series · Opal glass wall
Gold Luna Duo Ceiling Light
QN 39318-387Two opal-glass spheres suspended from a single brushed-gold ceiling plate, each Ø100 globe lit by its own 7.8W Bridgelux 2835 engine at 3000K, CRI90, with a trailing-edge dimmable 8W driver per globe. The doubled version of the Luna sconce — one fixture, one point of fixing, twice the glow. Finished in Gold.
Gold Luna Duo Ceiling Light (QN 39318-387) is built as a ceiling luminaire and specified at LED 2×7.8W, with 3000K, a colour rendering index of CRI 90 and IP20 ingress protection. It is finished in Gold, and is typically specified for hotel, residential, retail schemes. Dimensioned drawings are shown below, photometric files are downloadable on this page, and finish samples are available on request.
| Luminous flux, lm | 1633lm (3000K, measured) / 2640lm (2×1320lm, vendor) |
| CCT, K | 3000K |
| Power consumption, W | 2×7.8W (module) / 19.7W measured incl. driver · AC 220-240V |
| Color rendering (CRI) | 90 |
| Luminous efficacy | 82.9 lm/W |
| Light distribution | Semi-direct — 31.6% up / 68.4% down |
| Light source | Bridgelux 2835 SMD ×2 |
| Driver output | KGP 8W, trailing-edge dimmable ×2 |
| IP Code | IP20 |
| Size | 190 × 80 × 100mm |
| Finishes |
Applications
HotelResidentialRetail
Configure Luna
Control
Dimensions & mounting
| Mounting | Ceiling |
| Dimensions, mm | 190 × 80 × 100mm |
| Luminous surface, mm | Ø100 (each globe) |
| Case material | Glass + metal |
