White Sprout Garden Set
QN 26221-410Four tall stems, the highest at 1.2 m, lifting the light above low planting so a border is lit from within rather than from the path edge. The wide 110° distribution washes leaves close to the head and fades gently outward. Supplied as a complete four-piece set on a single order code.
White Sprout Garden Set (QN 26221-410) is built as a ground luminaire and specified at LED 22W, with 3000K (4000K / 6500K on request), a colour rendering index of CRI 80 and IP65 ingress protection. It is finished in Sandy White, and is typically specified for garden, landscape, terrace, hotel grounds schemes. Dimensioned drawings are shown below; IES / LDT photometric files and finish samples are supplied on request for specification and lighting-calculation work.
| Luminous flux, lm | 273lm per pole (vendor, 3000K) · ≈1090lm set |
| CCT, K | 3000K (4000K / 6500K on request) |
| Power consumption, W | 4 × 5.5W = 22W (set total) · 90–265V ~ 50/60Hz |
| Color rendering (CRI) | 80 |
| Light source | SMD LED · 24 per head |
| IP Code | IP65 |
| Size | Ø 60–75 heads · 600–1200 mm |
| Finishes | Sandy White |
Applications
Configure Sprout
CCT
Dimensions & mounting
| Mounting | Ground spike · surface screw (order option) |
| Dimensions, mm | Ø 60–75 heads · 600–1200 mm |
| Case material | Aluminum + PMMA |
| Working temperature | −10°C to +45°C |
| Warranty | 3 years |
Light distribution — cd/klm
